Camelion USB C rechargeable lithium batteries AA – 1.5V – 2200mWh

The Camelion Rechargeable Lithium Batteries 1.5V Li-AA2200mWh offers high performance and reliability, designed for various electronic devices. Its rated capacity of 1300mAh and stable 1.5V output ensures long-lasting power. Featuring Type-C charging and robust safety mechanisms, this battery delivers efficient energy with fast charging and safe discharging. Camelion Rechargeable Lithium Batteries are ideal for high-drain devices, it provides dependable performance under both high and low temperatures.

Cell Specifications

• Rated Voltage: 1.5V ±0.05V
• Charge Limited Voltage: Type-C 5V
• Discharge-off Voltage: 0.8V
• Rated Capacity: 1.5V@1300mAh (0.2C discharge)
• Minimum Capacity: 1.5V@1200mAh (0.2C discharge)
• Charging Method: Constant current and constant voltage (CC-CV)
• Standard Charging Current: Type-C 500mA ±50mA
• Standard Discharge Current: 400mA
• Rapid Charging Current: 500mA ±50mA
• Rapid Discharge Current: 2000mA
• Storage Temperature: -20°C to +50°C (Less than 1 month), -20°C to +35°C (Less than 6 months)

Product Endurance

• Cycle Life: After 50 charge-discharge cycles at 23°C, the cycle life should be ≥ 300 cycles without explosion, fire, or leakage.
• Low Temperature Discharge: Discharged at -10°C ±2°C, the discharge time should not be less than 3 hours.
• High Temperature Discharge: Discharged at 55°C ±2°C, the discharge time should not be less than 5 hours.

Mechanical Characteristics and Safety Tests

• Vibration Test: Vibration test across XYZ axes for 30 minutes at frequencies ranging from 10Hz to 55Hz.
• Drop Test: Dropped from a height of 1 meter twice onto a concrete surface.
• Constant Damp Heat Test: Exposure to 40°C ±2°C and 90%-95% humidity for 48 hours.

Handling Precautions

• Charging: Only charge within 10°C~45°C. Reverse charging is prohibited.
• Discharging: Maximum discharge current must not be exceeded. Discharge temperature range: -10°C to 60°C.
• Over-Discharging: Batteries should be periodically charged to 50%-70% to avoid over-discharging.

Handling & Storage

• Storage: Store in a cool, dry, and well-ventilated area.
• Disposal: Follow local regulations for battery disposal.

Protection Circuit (PCM)

• Overcharge Protection: Limited charge voltage 4.15-4.25V
• Over-Discharge Protection: Over-discharge detection voltage 2.7-2.8V
• Over-Current Protection: Protects against over-discharge currents between 2A and 4A.
